The hydraulic and air pressure system of the machine can load average, which can reach the standard of GB/T3810.4-2016, ISO10545-4:2014 ceramic tile testing requirement. It is widely used in the MOR testing of ceramic pipe, glaze tile, sanitary ware, electric ceramic, and fire-resistance materials. After replacing the tools, it can also be used to test the bursting strength etc.
Max loading capacity: 10000(N)
Tile size: 100*100~600*600, 100*100~800*800, 100*10~1000*1000(mm), Customized specifications of 100*10~1200*1200mm are also available
Loading speed: 5~700(N/S)
The data is processed by the micro computer, so that it can reach the accuracy of 0.5%
Power supply: Single-phase, 220V, 50HZ.
It can be loaded at constant speed and display the loading rate digitally. It can be loaded at constant speed according to GB/T3810.4-2016 and ISO 10545-4-2014 standards: 1N/(mm2*S)+0.2N/(mm2*S).
Intelligent ceramic bending tester adopts a deceleration motor speed regulation and loading mechanism, as well as a touch screen microcomputer control, calculation, and display. It meets the requirements of GB/T3810.4-2016 and ISO10545-4:2014, and is also suitable for measuring the flexural strength and compressive strength of engineering ceramics, electrical ceramics, daily ceramics, ceramic pipes, and brick and tile products. Replacing fixtures can also be used to measure parameters such as burst resistance.
Maximum load 10000N;
Loading rate: 1-700N/S adjustable (digital adjustable);
Sample size range: 60*60~600*600, 60*60~800*800, adjustable within the range of 60*60~1000*1000(mm), with three specifications to choose from. Additionally, 1200*1200mm specifications can be customized according to customer requirements;
Data computer processing with an accuracy of 0.5%;
Touch screen microcomputer display window: instantaneous pressure display, peak pressure display, loading speed display, sample size input, parameter setting interface, calibration interface and other functions;
The destructive strength S and fracture modulus R are automatically calculated by the machine;
Power supply: 220V, power 0.2KW
Ceramic Tester Detail View
Ceramic Tester Operation View
